Product Description:
WDG10/12QL is a high performance electric counterbalance forklift truck. It is designed for indoor and outdoor applications in medium-sized warehouses and depots. With a maximum load capacity of 1,000kg, a lead acid battery of 24V-85Ah/120Ah, and a lowered mast height of 2080/1840/2090/2340mm, the WDG10/12QL has exceptional ground clearance of 30mm and a service weight of 553kg with battery. This truck offers a wide range of features to make your lifting operations easier and faster, including a lift height of 1600mm and a smooth, efficient operation. The WDG10/12QL is perfect for efficient and safe material handling in any environment.
Features:
- 1) Low voltage protection system to extend battery life;
- 2) Using adjustable balance wheel, the car walks smoothly;
- 3) The whole vehicle is small, flexible, and has good maneuverability, and can work efficiently in places with narrow spaces;
- 4) It has good shock absorption effect, and the balance wheel assembly can be disassembled as a whole, which is convenient for maintenance and warranty.
Technical Parameters:
| Model |
WDG10QL |
| Load capacity |
1000kg |
| Tyre size, front |
φ80×70 |
| Tyre size, rear |
φ210×70 |
| Lift height |
1600/2500/3000/3500mm |
| Lowered height |
90mm |
| Overall length |
1750mm |
| Fork dimensions |
1070×142×60mm |
| Distance between fork arms |
550/660mm |
| Turning radius |
1437mm |
| Groung clearance |
30mm |
| Travel speed |
3.5/4 km/h |
| Gradient,Laden/unladen |
3/10% |
| Drive motor |
0.6kw |
| Lift motor |
2kw |
| Battery |
lead-acid 24V 65Ah |
Applications:
AIDA WDG10/12QL is the perfect solution for any application where a heavy-duty industrial electric forklift is required. It features a maximum speed of 6 km/h, a turning radius of 1400 mm, a maximum gradient of 3%/10%, a service weight of 553 kg with a lead-acid battery, and an overall width of 790 mm. The width over forks is 550/660 mm, and the minimum order quantity is 1. This product is CE certified and is available at a negotiable price, with delivery time of 10-15 days. Payment terms are available in TT.
Support and Services:
WDG10/12QL Technical Support and Service
We provide a range of technical support and service options for the WDG10/12QL product.
- Online support – Our website offers a range of product guides, FAQs and troubleshooting advice.
- Phone support – Our technical support team is available via phone to answer any questions you may have about the product.
- On-site support – We can provide on-site technicians to help you with installation, setup and maintenance of the WDG10/12QL product.
- Software updates – We will provide regular software updates to ensure your product is always up to date.
- Warranty – We offer a one-year warranty on all WDG10/12QL products.
Packing and Shipping:
Packaging and Shipping for WDG10/12QL
The WDG10/12QL is securely packaged in a cardboard box to ensure it is not damaged during shipping. The box also includes foam inserts for extra protection. The product is then shipped via a reliable carrier to ensure it arrives on time and in good condition.
FAQ:
Questions and Answers about AIDA WDG10/12QL
Q1: What is the Brand Name of AIDA WDG10/12QL?
A1: The Brand Name of AIDA WDG10/12QL is AIDA.
Q2: What is the Model Number of AIDA WDG10/12QL?
A2: The Model Number of AIDA WDG10/12QL is WDG10/12QL.
Q3: Where is AIDA WDG10/12QL from?
A3: AIDA WDG10/12QL is from China.
Q4: What is the Certification of AIDA WDG10/12QL?
A4: The Certification of AIDA WDG10/12QL is CE.
Q5: What is the Minimum Order Quantity of AIDA WDG10/12QL?
A5: The Minimum Order Quantity of AIDA WDG10/12QL is 1.
Q6: What is the Price of AIDA WDG10/12QL?
A6: The Price of AIDA WDG10/12QL is Negotiated.
Q7: How long does it take to deliver AIDA WDG10/12QL?
A7: It takes 10-15days to deliver AIDA WDG10/12QL.
Q8: What's the Payment Terms of AIDA WDG10/12QL?
A8: The Payment Term is TT.
