Product Details
Place of Origin: China
Brand Name: AIDA
Certification: ISO,CE,EGS
Model Number: WCT15QC
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: pallet packing for export
Delivery Time: 5-20 work days as per order volume
Payment Terms: T/T,L/C
Supply Ability: 200 set/month
Model NO.: |
WCT15QC |
Fuel: |
Electric |
Load Center: |
>500mm |
Lift Height: |
190mm |
Overall Width: |
550/680mm |
Overall Length: |
1670mm |
Lift Motor: |
800W |
Drive Motor: |
750/850W |
Specification: |
150kg |
HS Code: |
84279000 |
Type: |
Powered Pallet Truck |
Power: |
DC Motor |
Load Capacity: |
1T - 5T |
Model NO.: |
WCT15QC |
Fuel: |
Electric |
Load Center: |
>500mm |
Lift Height: |
190mm |
Overall Width: |
550/680mm |
Overall Length: |
1670mm |
Lift Motor: |
800W |
Drive Motor: |
750/850W |
Specification: |
150kg |
HS Code: |
84279000 |
Type: |
Powered Pallet Truck |
Power: |
DC Motor |
Load Capacity: |
1T - 5T |
1) Optional floating balance wheel, the car walks more stably;
2) The fork is integrally stamped, which is light and has a higher load;
3) Integral rocker arm design, stable driving and high structural strength;
4) The whole vehicle has a compact structure, integrated electrical layout, and easy maintenance.
| Model | WCT15QC |
| Load capacity | 1500kg |
| Rear Wheel Base | 390/520mm |
| Max.lifting height | 190mm |
| Lowered fork Height | 75/85mm |
| Overall length | 1626mm |
| Overall width | 550/680mm |
| Travel speed | 4.2/4.5 km/h |
| Gradient,Laden/unladen | 6/10% |
| Drive motor | 750w |
| Lift motor | 800w |
| Battery | Lead-acid 24V 65/85Ah Lithium 24V40Ah |
